Start Injection molding

Once your design ready and optimized for injection molding, what’s next? In this section we’ll take you through the steps needed to start manufacturing with injection molding.

Step 1: Start small and prototype fast

Before you commit to any expensive injection molding tooling, first create and test a functional prototype of your design.

This step is essential for launching a successful product. This way design errors can be identified early, while the cost of change is still low.

There are 3 solutions for prototyping:

3D printing (with SLS, SLA or Material Jetting)

CNC machining in plastic

Low-run injection molding with 3D printed molds

These processes can create realistic prototypes for form and function that closely resemble the appearance of the final injection molding product.

Use the information below as a quick comparison guide to decide which solution is best for your application.

Step 2: Make a “pilot run” (500 - 10,000 parts)

With the design finalized, it time to get started with Injection molding with a small pilot run.

The minimum order volume for injection molding is 500 units. For these quantities, the molds are usually CNC machined from aluminum. Aluminum molds are relatively easy to manufacture and low in cost (starting at about $3,000 to $5,000) but can withstand up to 5,000 - 10,000 injection cycles.

At this stage, the typical cost per part varies between $1 and $5, depending on the geometry of your design and the selected material. The typical lead time for such orders is 6-8 weeks.

Don’t get confused by the term “pilot run”. If you only require a few thousand parts, then this would be your final production step.

The parts manufactured with “pilot” aluminum molds have physical properties and accuracy identical to parts manufactured with “full-scale production” tool steel molds.

Step 3: Scale up production (100,000+ parts)

When producing parts massive quantities of identical parts (from 10,000 to 100,000+ units) then special Injection molding tooling is required.

For these volumes, the molds are CNC machined from tool steel and can withstand millions of Injection molding cycles. They are also equipped with advanced features to maximize production speeds, such as hot-tip gates and intricate cooling channels.

The typical unit cost at this stage varies between a few cents to $1 and the typical lead time is 4 to 6 months, due to the complexity of designing and manufacturing the mold.
